58
sEAlING GlUEs FOR MECHANICAl DETAIls
NBQ GAsKET sEAlING GlUEs
GLUEs
NBQ Gasket sealing glues are designed for sealing and connecting different mechanical de-
tails during assembly. NBQ Gasket series includes glues for various purposes - glues for
connecting similar and different type of materials, flexible and rigid glues, glues with high
temperature resistance etc.
GENERAL INFORmATION
NBQ Gasket Thixo - withstands high temperatures and the content is very thin
NBQ Gasket Medium - medium strenght and wuth very good flexibility
NBQ Gasket Fill - Medium strength glue suitable for replacing old gaskets
• Clean the surfaces before the connection, if possible
• Apply glue and fix the connections
• when completed make sure the package of the glue is closed to prevent the product
from drying out
APPLICATIONs
INsTRUCTIONs FOR UsE
PROdUCT ANd ACCEssORIEs
TEChNICAL INFORmATION
NBQ GAsKET ThIxO
NBQ GAsKET mEdIUm
NBQ GAsKET FILL
Colour
orange
red
orange
Temperature resistance
-50 ºC to +200 ºC
-50 ºC to +150 ºC
-50 ºC to +150 ºC
Viscosity cps
250000-600000
300000-700000
50000-150000
shear strenght
2-8 Nm
4-11 Nm
1.5-6 Nm
Fixing time
20 min
35 min
20 min
Drying time
24h
24h
24h
Maximum gap fill
0.50 mm
0.5 mm
0.35 mm
storage time
12 months in closed package
12 months in closed package
12 months in closed package
PROdUCTs
PACKAGE
COdE
shORT COdE PROdUCT GOUP LOCTITE ANALOGUE
EAN COdE
NBQ GAsKET THIxO
50ml
NBQ574005
G510
Glues
510
4742628001194
NBQ GAsKET MEDIUM 50ml
NBQ549205
G018
Glues
518
4742628000999
NBQ GAsKET FIll
50ml
NBQ549105
G074
Glues
574
4742628000982
AUxILIARY PROdUCTs
BRAKE ClEANER
500ml
NBQ492050
C10
Cleaning
–
4742628000524
