plUGFlUx CONNECTIONs
pREssABlE wATERTIGHT plUG CONNECTIONs FOR wIREs
ELECTRICAL
Plugflux connections are high quality connections designed for use
in difficult conditions, where good connection and weather resis-
tance is important. The product consists of a pressable plug connec-
tion and a transparent heat-shrinkable tube that contains hot-melt
glue to protect the connection from water and weather conditions.
Plugflux is quick and easy to use.
GENERAL INFORmATION
Quick and quality making of different wire connections - cars, heavy machinery, trucks,
industrial applications, marine wire connections etc.
• Clean the wires before installation.
• Insert the wire in Plugflux and heat the wire connection with the gas burner towards the
wire to prevent air bubbles.
• Keep heating until you see that the sealing glue has melted to the wire.
• The connection is completed after it has cooled.
Contents
stick connection, heat-shrinkable insulation, hot-melt glue
Colour
red/blue/yellow
Temperature resistance
-60 ºC to +130 ºC
Operating temperature
from +180 ºC
dielectric resistance
2400 V
Insulation resistance
>106 MegaOhm
Breakdown voltage
>600 V
Chemical resistance
diesel, brake fluid, coolant, motor oil
heat-shrinking ratio of the tube
2:1
• Connecting, insulating and
sealing
• Perfectly watertight connections
• very quick installation
TEChNICAL INFORmATION
APPLICATIONs
INsTRUCTIONs FOR UsE
PROdUCT ANd ACCEssORIEs
PROdUCT
PACKAGE
COdE
shORT COdE PROdUCT GROUP
EAN COdE
plUGFlUx CONNECTION RED
0.25-1.5 mm²
NBQ800030
–
Electrical
–
plUGFlUx CONNECTION BlUE
1.5-2.5 mm²
NBQ800031
–
Electrical
–
plUGFlUx CONNECTION yEllOw 3.0-6.0 mm²
NBQ800032
–
Electrical
–
plUGFlUx MAlE RED
0.25-1.5 mm²
NBQ800035
–
Electrical
–
plUGFlUx MAlE BlUE
1.5-2.5 mm²
NBQ800036
–
Electrical
–
plUGFlUx FEMAlE RED
0.25-1.5 mm²
NBQ800040
–
Electrical
–
plUGFlUx FEMAlE BlUE
1.5-2.5 mm²
NBQ800041
–
Electrical
–
AUxILIARY PROdUCTs
MINI GAs BURNER FACOM
500ml
FC1075.G
–
Tools
–
