74
TAPEs
IsOlATION TApE
IsOlATION TApE
Isolation Tape is an isolation tape which is meant for isolating of different electric conductors and cables. There are two versions of Isolation
Tape - the normal one and the stronger one, which has a higher temperature resistance The product has excellent elongation and isolation
features.
GENERAL INFORmATION
Isolation and protection of different electric conductors and cables upon their repair. The
product is also suitable for repair of damaged isolation.
• Transport, store and use the product between the temperatures from 0
ºC
to +30
ºC
.
• The surfaces to be glued must be dry, clean and free from dust - clean the surfaces in
advance, if necessary.
• Wind the tape firmly around the material and cover evenly.
• The product achieves its total bonding strength after 24 hours.
NB!
In case of complex and silicone-based plastics, use a plastic primer in order to
achieve a better adhesion between the materials.
• Great adherence
• Excellent isolation features
• Easy to use
APPLICATIONs
INsTRUCTIONs FOR UsE
PROdUCT ANd ACCEssORIEs
PROdUCT
PACKAGE
COdE
shORT COdE PROdUCT GROUP
EAN COdE
IsOlATION TApE
15mm x 10m NBQ551002
T91
Tapes
–
IsOlATION TApE 2
19mm x 20m NBQ551003
T92
Tapes
–
TEChNICAL INFORmATION
IsOLATION TAPE
IsOLATION TAPE 2
Basic components
pVC carrier, rubber-based adhesive
pVC carrier, rubber-based adhesive
Colour
black
black
Temperature resistance
from -20 ºC to +80 ºC
from -20 ºC to +90 ºC
Application temperature
from 0 ºC to +35 ºC
from 0 ºC to +35 ºC
Adhesion to steel
1,8N/cm
1,8N/cm
Tensile strenght
28N/cm
28N/cm
Elongation
200%
150%
Dielectric strength
6000V
7000V
Thickness
0,15mm
0,15mm
shelf life
12 months in sealed packaging
12 months in sealed packaging
