ANAEROBIC THREAD lOCKING GlUEs
NBQ lOCK THREAD lOCKING
GLUEs
NBQ lock thread and sealing glues are based on anaerobic adhe-
sive technology and designed for sealing different threaded con-
nections. The product selection includes thread locking glues with
different strength, viscosity and temperature resistance. NBQ lock
Activator is recommended for locking aluminium and steel materi-
als and it also accelerates the drying time of other NBQ lock glues.
NBQ lock glues have a quick drying time and long-term durability.
GENERAL INFORmATION
sealing and locking different industrial and automotive threaded connections.
• Clean the surfaces before the connection, if possible.
• Apply glue and fix the connections.
• when completed make sure the package of the glue is closed to prevent the product fro
drying out.
The activator of anaerobic adhesives significantly increases their drying time!
APPLICATIONs
INsTRUCTIONs FOR UsE
PROdUCT ANd ACCEssORIEs
TEChNICAL INFORmATION NBQ LOCK sCREw NBQ LOCK
sEmI-mEdIUm NBQ LOCK mEdIUm NBQ LOCK sTRONG NBQ LOCK ThIN
Basic substances
dimethylacrylate
dimethylacrylate
dimethylacrylate
dimethylacrylate
dimethylacrylate
Colour
purple
blue
blue
green
green
Temperature resistance
-55 ºC to +150 ºC
-55 ºC to +150 ºC
-55 ºC to +150 ºC
-50 ºC to +150 ºC
-55 ºC to +150 ºC
Viscosity cps
4000-6000
4000-6000
10000-18000
400-600
7-12
Breakaway torque
5-11 Nm
8-18 Nm
12-25 Nm
20-40 Nm
7-21 Nm
prevail torque
1-5 Nm
2-10 Nm
5-15 Nm
21-44 Nm
25-44 Nm
Fixing time
15 min
<15 min
<15 min
15 min
15 min
Drying time
24h
24h
24h
24h
24h
Maximum gap fill
0.25 mm
0.25 mm
0.30 mm
0.20 mm
0.15 mm
storage time
12 months in closed
package
12 months in closed
package
12 months in closed
package
12 months in closed
package
12 months in closed
package
PROdUCTs
PACKAGE
COdE
shORT
COdE
PROdUCT GOUP LOCTITE ANALOGUE
EAN COdE
NBQ lOCK sCREw 50ml
NBQ544005
G22
Glues
222
4742628000920
NBQ lOCK sEMI-MEDIUM 50ml
NBQ549405
G42
Glues
242
4742628001088
NBQ lOCK MEDIUM
10ml
NBQ541001
G43
Glues
243
4742628000463
NBQ lOCK MEDIUM
50ml
NBQ541005
G43
Glues
243
4742628000470
NBQ lOCK sTRONG
10ml
NBQ542001
G70
Glues
270
4742628001026
NBQ lOCK sTRONG
50ml
NBQ542005
G70
Glues
270
4742628000494
NBQ lOCK THIN
50ml
NBQ549505
G90
Glues
290
4742628001095
NBQ lOCK ACTIVATOR 200ml
NBQ540020
–
Glues
–
4742628001101
AUxILIARY PROdUCTs
BRAKE ClEANER
500ml
NBQ492050
C10
Cleaning
–
4742628000524
