59
NBQ lOCK pIpE & HyDRO
pIpE AND HyDRAUlICs sEAlING GlUEs
GLUEs
NBQ lock pipe glues designed for sealing pipe connections. The
products have different viscosities and very high temperature resis-
tance. NBQ lock Hydro is an anaerobic sealing glue for hydraulic
connections and ideal for use with hydraulic fluids.
GENERAL INFORmATION
NBQ lock Hydro - sealing and connecting pneumatic and hydraulic threaded connections.
NBQ lock pipe low - sealing pipe connections that require easy demounting in the future.
NBQ lock pipe Medium - sealing pipe connections that require immediate pressure resis-
tance and also greater vibration tolerance.
• Clean the surfaces before the connection, if possible
• Apply glue and fix the connections
• when completed make sure the package of the glue is closed to prevent the product from
drying out
APPLICATIONs
INsTRUCTIONs FOR UsE
PROdUCT ANd ACCEssORIEs
PROdUCTs
PACKAGE
COdE
shORT COdE PROdUCT GOUP LOCTITE ANALOGUE
EAN COdE
NBQ lOCK HyDRO
50ml
NBQ543005
G042
Glues
542
4742628000685
NBQ lOCK pIpE lOw 50ml
NBQ548105
G065
Glues
565
4742628001187
NBQ lOCK pIpE MEDIUM 50ml
NBQ549305
G077
Glues
577
4742628001019
AUxILIARY PROdUCTs
BRAKE ClEANER
500ml
NBQ492050
C10
Cleaning
–
4742628000524
TEChNICAL INFORmATION
NBQ LOCK hYdRO
NBQ LOCK PIPE LOw
NBQ LOCK PIPE mEdIUm
Colour
brown
white
yellow
Temperature resistance
-50 ºC to +150 ºC
-50 ºC to +150 ºC
-50 ºC to +150 ºC
Viscosity cps
400-600
150000-450000
35000-60000
Breakaway torque
8-18 Nm
2-8 Nm
8-20 Nm
prevail torque
7-14 Nm
0.5-4 Nm
2-8 Nm
Fixing time
15 min
120 min
15 min
Drying time
24h
24h
24h
Maximum gap fill
0.20 mm
0.50 mm
0.25 mm
storage time
12 months in closed package
12 months in closed package
12 months in closed package
