NB Quality Catalogue - page 55

55
NBQ lOCK BEARING GlUEs
ANAEROBIC BEARING lOCKING GlUEs
GLUEs
NBQ lock Bearing glues are based on anaerobic glue technology
and designed for the installation of bearings. The product selection
includes bearings glues with different strength, viscosity and tempera-
ture resistance. NBQ lock Activator is recommended for locking alu-
minium and steel materials and it also accelerates the drying time of
other NBQ lock Bearing glues.
NBQ lock Bearing glues have a quick drying time and long-term
durability.
GENERAL INFORmATION
Installation of different industrial and automotive bearings.
• Clean the surfaces before the connection, if possible.
• Apply glue and fix the connections.
• when completed make sure the package of the glue is closed to prevent the product from
drying out.
The activator of anaerobic adhesives significantly increases their drying time!
APPLICATIONs
INsTRUCTIONs FOR UsE
PROdUCT ANd ACCEssORIEs
TEChNICAL
INFORmATION
NBQ LOCK
BEARING m
NBQ LOCK BEARING
s PRECIsE
NBQ LOCK
BEARING s
NBQ LOCK BEARING
ss dYNAmIC
NBQ LOCK BEARING
s hI-TEmP
Basic substances dimethylacrylate dimethylacrylate dimethylacrylate dimethylacrylate dimethylacrylate
Colour brownish green green green green
Temperature resistance -50 ºC to +150 ºC -50 ºC to +150 ºC -55 ºC to +150 ºC -50 ºC to +150 ºC -55 ºC to +150 ºC
Viscosity cps 400-600 100-150 400-800 1800-3300 10000-30000
Breakaway torque 12-18 Nm 25-41 Nm 20-40 Nm 25-42 Nm 25-42 Nm
prevail torque 8-12 Nm 25-40 Nm 13-40 Nm 25-42 Nm 25-42 Nm
shear strenght 7-15 Nm 15-28 Nm 20-33 Nm 17-37 Nm 15-32 Nm
Fixing time 15 min 15 min 10 min <15 min 15 min
Drying time 24h 24h 24h 24h 24h
Maximum gap fill 0.20 mm 0.20 mm 0.20 mm 0.25 mm 0.40 mm
storage time 12 months in closed
package
12 months in closed
package
12 months in closed
package
12 months in closed
package
12 months in closed
package
PROdUCTs PACKAGE COdE shORT
COdE
PROdUCT
GOUP LOCTITE ANALOGUE EAN KOOd
NBQ lOCK BEARING M 50ml NBQ548005 G041 Glues 641 4742628000951
NBQ lOCK BEARING s pRECIsE 50ml NBQ549805 G001 Glues 601/603 4742628001149
NBQ lOCK BEARING s 50ml NBQ549005 G048 Glues 648 4742628000975
NBQ lOCK BEARING ss DyNAMIC 50ml NBQ547005 G038 Glues 638 4742628000968
NBQ lOCK BEARING s HI-TEMp 50ml NBQ549905 G020 Glues 620 4742628001156
NBQ lOCK ACTIVATOR 200ml NBQ540020 – Glues – 4742628001101
AUxILIARY PROdUCTs
BRAKE ClEANER 500ml NBQ492050 C10 Cleaning – 4742628000524
