57
NBQ lOCK HI-TEMp THREAD
ANAEROBIC THREAD lOCKING GlUEs wITH HIGH TEMpERATURE REsIsTANCE
GLUEs
NB lock Hi-Temp thread and sealing glues are based on anaerobic
adhesive technology and designed for sealing different connections
that require high temperature resistance. The product selection in-
cludes two thread locking glues with different viscosity. NBQ lock
Activator is recommended for locking aluminium and steel materi-
als and it also accelerates the drying time of other NBQ lock glues.
NBQlockHi-Tempglueshaveaquickdryingtimeandlong-termdurability.
GENERAL INFORmATION
sealing and connecting different industrial and automotive threads that require high tempe-
rature resistance.
• Clean the surfaces before the connection, if possible
• Apply glue and fix the connections
• when completed make sure the package of the glue is closed to prevent the product from
drying out
The activator of anaerobic adhesives significantly increases their drying time!
APPLICATIONs
INsTRUCTIONs FOR UsE
PROdUCT ANd ACCEssORIEs
PROdUCTs
PACKAGE
COdE
shORT COdE PROdUCT GOUP LOCTITE ANALOGUE EAN COdE
NBQ lOCK HI-TEMp
50ml
NBQ549605
G72
Glues
272
4742628001125
NBQ lOCK HI-TEMp 2
50ml
NBQ549705
G77
Glues
277
4742628001132
NBQ lOCK ACTIVATOR 200ml
NBQ540020
–
Glues
–
4742628001101
AUxILIARY PROdUCTs
BRAKE ClEANER
500ml
NBQ492050
C10
Cleaning
–
4742628000524
TEChNICAL INFORmATION
NBQ LOCK hI-TEmP
NBQ LOCK hI-TEmP 2
Basic substances
dimethylacrylate
dimethylacrylate
Colour
red
red
Temperature resistance
-50 ºC to +230 ºC
-50 ºC to +230 ºC
Viscosity cps
15000-30000
6000-8000
Breakaway torque
20-37 Nm
20-37 Nm
prevail torque
15-40 Nm
15-40 Nm
Fixing time
<15 min
<15 min
Drying time
24h
24h
Maximum gap fill
0.30 mm
0.30 mm
storage time
12 months in closed package
12 months in closed package
