wIRE CONNECTIONs wITH INTERNAl sOlDER
INTERFlUx
ELECTRICAL
Interflux is a quality wire connection with an internal solder. The prod-
uct solders, seals and also insulates. Thanks to the transparent in-
sulation layer of Interflux the quality of the product connection can
be checked visually. The product is suitable for flexible as well as
moderately rigid wires. Interflux includes solder wire rings, adhesive-
sealing rings at the ends and a transparent shrinking insulation layer.
GENERAL INFORmATION
Quick and quality connection and insulation of different wires - cars, heavy machinery, trucks,
industrial applications, marine wire connections etc.
• Clean the wires before installation.
• Cross the wires and place Interflux on the connection so the part with solder wire is on
the part that needs to be soldered and then press the solder ring to fix Interflux.
• Heat the wire connection with the gas burner from centre to outwards to prevent air bubbles.
• Keep heating until the solder wire melts and then heat the glue rings at the end of the
wire connection to seal the connection.
• The connection is completed after it has cooled.
Contents
radiation-modified polyolefins, solder rings, thermoplastic glue rings,
thermoplastic sleeve
Colour
white/red/blue/yellow
Temperature resistance
-50 ºC to +130 ºC
Operating temperature
from +180 ºC
voltage loss
<0.002 V
Connection resistance
<0.004 Ohm
Insulation resistance
>109 Ohm
Breakdown voltage
>600 V
• Connecting, soldering,
insulating and sealing
• Perfectly watertight connections
• very quick installation
• Quality solder
TEChNICAL INFORmATION
APPLICATIONs
INsTRUCTIONs FOR UsE
PROdUCT ANd ACCEssORIEs
PROdUCT
PACKAGE
COdE
shORT COdE PROdUCT GROUP
EAN COdE
INTERFlUx wHITE
0.2-0.7 mm²
NBQ800001
Electrical
–
INTERFlUx RED
0.5-1.5 mm²
NBQ800002
Electrical
–
INTERFlUx BlUE
1.5-2.5 mm²
NBQ800003
Electrical
–
INTERFlUx yEllOw
3.0-6.0 mm²
NBQ800004
Electrical
–
AUxILIARY PROdUCTs
MINI GAs BURNER FACOM
500 ml
FC1075.G
Tools
–
