93
FORKFlUx CONNECTIONs
pREssABlE wATERTIGHT FORK CONNECTIONs FOR wIREs
ELECTRICAL
Forkflux connections are high quality connections designed for use in
difficult conditions, where good connection and weather resistance is
important. The product consists of a pressable fork connection and a
transparent heat-shrinkable tube that contains hot-melt glue to pro-
tect the connection from water and weather conditions. Forkflux is
quick and easy to use.
GENERAL INFORmATION
Quick and quality making of different wire connections - cars, heavy machinery, trucks,
industrial applications, marine wire connections etc.
• Clean the wires before installation.
• Insert the wire in Forkflux and heat the wire connection with the gas burner towards the
wire to prevent air bubbles.
• Keep heating until you see that the sealing glue has melted to the wire.
• The connection is completed after it has cooled.
Contents
fork connection, heat-shrinkable insulation, hot-melt glue
Colour
red/blue/yellow
Temperature resistance
-60 ºC to +130 ºC
Operating temperature
from +180 ºC
dielectric resistance
2400V
Insulation resistance
>106 MegaOhm
Breakdown voltage
>600 V
Chemical resistance
diesel, brake fluid, coolant, motor oil
heat-shrinking ratio of the tube
2:1
• Connecting, insulating and
sealing
• Perfectly watertight connections
• very quick installation
TEChNICAL INFORmATION
APPLICATIONs
INsTRUCTIONs FOR UsE
PROdUCT ANd ACCEssORIEs
PROdUCT
PACKAGE
COdE
shORT COdE PROdUCT GROUP
EAN COdE
FORKFlUx RED 4.3 MM
0.25-1.5 mm²
NBQ800045
–
Electrical
–
FORKFlUx BlUE 4.3 MM
1.5-2.5 mm²
NBQ800046
–
Electrical
–
FORKFlUx BlUE 5.3 MM
1.5-2.5 mm²
NBQ800047
–
Electrical
–
FORKFlUx yEllOw 5.3 MM
3.0-6.0 mm²
NBQ800048
–
Electrical
–
AUxILIARY PROdUCTs
MINI GAs BURNER FACOM
500ml
FC1075.G
–
Tools
–
