94
sHRINKTUBE
HEAT-sHRINKABlE TUBE wITH ADHEsIVE
ELECTRICAL
shrinktube is a unique heat-shrinking black insulation and protective
tube with double-walls. The external radiation-modified polyolefin lay-
er ensures tight insulation and the internal hot-melt glue layer ensures
watertightness. Thanks to its flexibility Shrinktube can also be used
with strong vibration and moving wires. The product is highly resistant
to weather as well as UV light.
GENERAL INFORmATION
Insulating wires and cables, protecting pipes and cables, protecting fuel and hydraulic
systems, protecting brake pipes, protecting metal pipes against corrosion, repairing
welding clamps, restoring tool handles etc.
• Clean the materials before installation, if possible.
• Cut shrinktube to the correct length (at least 50 mm excess at both ends).
• Heat the connection with the gas burner from the centre of the tube to outwards to prevent
air bubbles.
• Keep heating until you see sealing glue coming out of the tube ends.
• The connection is completed after it has cooled.
NB!
Avoid direct contact of the flame and the tube!
Contents
radiation-modified polyolefins, hot-melt glue
Colour
black
Temperature resistance
-60 ºC to +160 ºC
Operating temperature
from +125 ºC
dielectric resistance
30 MV/m
Elongation
up to 450%
Insulation resistance
1x1013 Ohm/cm
Chemical resistance
fuels - good
coolant, hydraulic oil - very good
heat-shrinking ratio of the tube
3:1
• Permanently flexible
• Good water and chemical
resistance
• Easy to use
TEChNICAL INFORmATION
APPLICATIONs
INsTRUCTIONs FOR UsE
PROdUCT ANd ACCEssORIEs
PROdUCT
PACKAGE
COdE
shORT COdE PROdUCT GROUP
EAN COdE
sHRINKTUBE 3/1MM
1,2m
NBQ810003
–
Electrical
–
sHRINKTUBE 4,5/1,5MM
1,2m
NBQ810004
–
Electrical
–
sHRINKTUBE 6/2MM
1,2m
NBQ810006
–
Electrical
–
sHRINKTUBE 9/3MM
1,2m
NBQ810009
–
Electrical
–
sHRINKTUBE 12/4MM
1,2m
NBQ810012
–
Electrical
–
sHRINKTUBE 19/6MM
1,2m
NBQ810019
–
Electrical
–
sHRINKTUBE 24/8MM
1,2m
NBQ810024
–
Electrical
–
sHRINKTUBE 40/13MM
1,2m
NBQ810040
–
Electrical
–
sHRINKTUBE 52/13MM
1,2m
NBQ810052
–
Electrical
–
AUxILIARY PROdUCTs
MINI GAs BURNER FACOM
500ml
FC1075.G
–
Tools
–
