INTERFlUx MUlTI
wIRE CONNECTIONs wITH INTERNAl sOlDER
ELECTRICAL
Interflux Multi is a quality quick wire-connector designed for connect-
ing multiple wires. The product consists of a copper cone and solder
wire that ensure a good solder connection, a ceramic ball that ensures
acid resistance and watertightness at one end, hot-melt glue that en-
sures watertightness at the wire end and a polymer shrinking protec-
tive layer that ensures an externally tight connection. Interflux Multi is
a very fast high quality product.
GENERAL INFORmATION
Quick and quality connection and insulation of different wires - cars, heavy machinery,
trucks, industrial applications, marine wire connections etc. Also suitable for connecting or
continuing wire bundles.
• Clean the wires before installation.
• Twist the wires that are to be joined into a bundle and turn them correctly clockwise into the
copper cone.
• Heat the wire connection with the gas burner from the thinner end of the tin cone to
outwards to prevent air bubbles.
• Keep heating until the solder wire melts and then heat the hot-melt glue and glue ring at
the end of the wire connection to seal the connection.
• The connection is completed after it has cooled.
Contents
flameproof polymer, copper cone, solder wire, thermoplastic glue ring
Colour
green/red/blue/yellow
Temperature resistance
-60 ºC to +130 ºC
Operating temperature
from +210 ºC
voltage loss
<0.002 V
Connection resistance
<0.004 Ohm
Insulation resistance
>109 Ohm
Breakdown voltage
>600 V
• Connecting, soldering,
insulating and sealing
• Perfectly watertight connections
• very quick installation
• Quality solder
TEChNICAL INFORmATION
APPLICATIONs
INsTRUCTIONs FOR UsE
PROdUCT ANd ACCEssORIEs
PROdUCT
PACKAGE
COdE
shORT COdE
PROdUCT GROUP EAN COdE
INTERFlUx MUlTI GREEN
up to 4 mm²
NBQ800011
–
Electrical
–
INTERFlUx MUlTI RED
up to 4.5 mm²
NBQ800012
–
Electrical
–
INTERFlUx MUlTI BlUE
up to 7 mm²
NBQ800013
–
Electrical
–
INTERFlUx MUlTI yEllOw
up to 9.5 mm²
NBQ800014
–
Electrical
–
AUxILIARY PROdUCTs
MINI GAs BURNER FACOM
500ml
FC1075.G
–
Tools
–
